Dynamic Pass Boxes are used for the transfer of material from an uncontrolled environment to a controlled environement, in isolation, by means of mechanical/electromagnetic door interlocking process which ensures opening of only one door at a time. This process helps in avoiding cross contamination between two areas.

Our comprehensive range of Schematic Dynamic Pass Boxes are offered as self-contained units which are installed at the entrance to clean room.

Our dynamic pass boxes help to minimise the amount of particulate contamination entering the clean room and also ensure to reduce the operator traffic.

Equipment and material can be passed into the clean room via the Schematic dynamic pass box, due to the electro mechanical interlock door system that prevents both doors from being opened at the same time.

Our range is highly affordable way to maintain the cleanliness of room, easy to install and adaptable to different working conditions.

Enquire Now

Design Features

  • Control Panel with LED and UV Light switches
  • Display panel with Wait/Go Indicators
  • Internal area hygienically design for ease of cleaning
  • HEPA Filters
  • Electromagnetic door locks (both sides)
  • Emergency exit button

Technical Specification

  • Single Door design
  • Conforms to cGMP
  • Material of Construction 304 Stainless Steel
  • Integrated with UV lamp and Hour Meter
  • EU14 HEPA filter
  • Customised Blower to suit sie/capacity
  • EU8 Pre-Filter

Operational Benefit

  • Electro magnetic interlocking doors ensures no unauthorised product entry during cycle

Applications

  • Clean Rooms
  • Laboratories
  • Hospitals
  • Pharmaceutical plants
  • Light-industrial environments

Supply Options

  • Material of Construction 316 Stainless Steel
  • Multiple entry (dual door)
